| System |
| CPU |
|
Intel® uFC-LGA 775 socket Supports Core 2 Duo Pentium® D / PentiumR 4 / Celeron® D with 65nm process technology |
| FSB |
|
1066/800/533 MHz |
| BIOS |
|
Award 4 Mb Flash BIOS |
| System Chipset |
|
Intel® 82945G GMCH/ ICH7 |
| I/O Chip |
|
Winbond W83627EHG-A |
| System Memory |
|
Four 240-pin DIMM sockets support up to 4 GB
Dual Channel DDR2 667/533 SDRAM |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| H/W Status Monitor |
|
Monitoring temperatures, voltages, and cooling fan status. Auto throttling control when CPU overheats |
| Expansion |
|
One PCI Express X16, one PCI Express X1,
five PCI slots (PCI Rev. 2.2 compliant) |
| I/O |
| MIO |
|
1 x EIDE (Ultra DMA 100), 4 x SATA, 1 x FDD,
1 x LPT, 1 x RS-232, 1 x RS-232/422/485,
1x K/B, 1 x Mouse |
| USB |
|
8 x USB 2.0 ports |
| Display |
| Chipset |
|
Intel® 82945G GMCH integrated Graphics
Media Ac-celerator 950 |
| Display Memory |
|
Intel® DVMT 3.0 supports 224 MB video memory |
| Max. 3D Resolution |
|
2048 x 1536 @ 32 bpp (75 Hz) |
| VGA/LCD Interface |
|
PCI-E X16 VGA interface |
| LVDS |
|
Through ADD2 LVDS Card
(Customized BIOS required) |
| DVI |
|
Through ADD2 DVI Card
(Customized BIOS required) |
| TV-out |
|
Through ADD2 TV-out Card
(Customized BIOS required) |
| Audio |
| Chipset |
|
Intel® ICH7 |
| AC97 Codec |
|
Realtek ALC 888, 7.1 CH High-Definition
Audio Codec |
| Audio Interface |
|
Mic in, Line in, CD Audio in, Line out, S/PDIF |
| Ethernet |
| LAN 1 |
|
Intel® 82573L Gigabit LAN |
| Back Panel I/O Port |
| Back Panel I/O Port |
|
* 1 x PS/2 Keyboard
* 1 x PS/2 Mouse
* 1 x Parallel port
* 1 x Serial port
* 1 x VGA port
* 1 x RJ45 port
* 4 x USB ports
* Audio I/O (3 jacks) |
| Internal I/O Connector |
| Internal I/O Port |
|
* 2 x USB connectors support
additional 4 USB ports
* 1 x 24-pin ATX Power connector
* 1 x 4-pin ATX 12V Power connector
* 1 x Floppy disk drive connector
* 1 x IDE connector for two devices
* 1 x COM connectors
* 1 x Chassis intrusion connector
* 1 x CD audio in connector
* 1 x TPM connector
* 4 x SATA connectors
* 1 x Front panel audio connector
* 1 x S/PDIF out connector
* 1 x Speaker connector
* 1 x System panel connector
* 1 x 3-pin Power LED connector
* 1 x CPU Fan connector
* 1 x Chassis Fan connector
* 1 x Power Fan connector |
| Mechanical & Environmental |
| Power Requirement |
|
+5 V @ 4.26 A, +12 V @ 10.12 A,
+3.3 V @ 722 mA (with Intel® Core 2
Duo E6400 2.13 GHz & 1 GB*2
DDR2 SDRAM) |
| Power Type |
|
ATX |
| Operating Temperature |
|
0~60°C (32~140°F) |
| Operating Humidity |
|
0%~90% relative humidity, non-condensing |
| Size (L x W) |
|
12" x 9.6" (304.8 mm x 243.84 mm) |
| Weight |
|
1.32 lbs (0.6 Kg) |
Specifications
